‹ Home › Inventory › 2025 Harley-Davidson® RA1250ST Pan America® 1250 ST U307467

STK# U307467T 2025 Harley-Davidson® Pan America® 1250 ST with only 3,525 actual miles. The bike features a custom seat, custom windshield and a custom Vance and Hines slip-on muffler. This won't last long! STK# U307467T 2025 Harley-Davidson® Pan America® 1250 ST with only 3,525 actual miles. The bike features a custom seat, custom windshield and a custom Vance and Hines slip-on muffler. This won't last long! Features may include: DESIGNLower Seat An all-new, one-piece seat lowers the rider's height for easier mounting and confident footing at stops. Its shape supports aggressive cornering while ensuring comfort and control. Front Fender Street-style lower fender hugs the Michelin® Scorcher Sport tire for a sleeker, more aerodynamic design. Blacked-Out Styling From the lightweight muffler to the front cylinder, the blacked-out powertrain is raw and aggressive, but also subtle and understated. PERFORMANCERevolution® Max 1250 Engine The liquid-cooled Revolution Max 1250 has a broad powerband with 149 horsepower and 94 ft-lb of torque at its peak. Integrated into the chassis as a load-bearing element, this engine not only shaves off weight but also improves rigidity for a more responsive ride. Wheels The 17-inch cast-aluminum wheels are built for fast handling and come stock with Michelin Scorcher Sport tires, boosting your street performance for sharper, more responsive rides. Adaptive Ride Height Standard on North American models, Adaptive Ride Height (ARH) drops up to one inch in a stopped position, allowing you to mount or dismount the Pan America 1250 ST with ease and confidence. Suspension Lowered suspension drops the center of gravity and eliminates unneeded ground clearance for optimal road performance. SHOWA® Balance Free 47mm forks and a SHOWA Balance Free monoshock feature electronically adjustable pre-load and manually adjustable compression and rebound. Brakes Dual front Brembo Monoblock radially mounted four-piston calipers and hub-mounted 320mm brake rotors provide incredible stopping power with direct lever feel, while trailing in the rear are a single-piston Brembo caliper and 280mm rotor. Quickshifter Click through the gears, up and down, without clutching or worrying about damaging your transmission. Quick, smooth shifts are achieved with little more than a tap of the foot, optimizing acceleration and keeping your focus on the road.

Specifications

Dimensions

add remove
- Length:

  88.2 in
- Ground clearance:

  6.7 in
- Rake (steering head):

  25
- Trail:

  3.7 in
- Wheelbase:

  61.8 in
- Tires, front specifications:

  120/70R19 60V
- Tires, rear specifications:

  180/55ZR17 73W
- Fuel Capacity:

  5.6 gal
- Oil capacity:

  4.75 qt.
- Weight, as shipped:

  507 lbs
- Weight, in running order:

  542 lb
Engine

add remove
- Engine:

  Revolution® Max 1250
- Bore:

  4.1 in
- Stroke:

  2.8 in
- Displacement:

  76.40 in³
- Compression ratio:

  13.0:1
- Fuel system:

  Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust:

  2-into-1-into-1; catalyst in header
Performance

add remove
- Engine torque testing method:

  J1349
- Engine torque:

  91.5 ft-lb
- Engine torque (RPM):

  6750
- Horsepower:

  149 HP / 111 kW @ 8750 rpm
- Lean angle, right (deg.):

  37
- Lean angle, left (deg.):

  37
- Fuel economy testing method:

  Estimated City/Hwy
- Fuel economy:

  46 mpg (5.1 l/100 km)
Powertrain

add remove
- Primary drive:

  Gear, 49/89 ratio
- Gear ratios (overall) 1st:

  13.11
- Gear ratios (overall) 2nd:

  9.687
- Gear ratios (overall) 3rd:

  7.509
- Gear ratios (overall) 4th:

  6.057
- Gear ratios (overall) 5th:

  5.08
- Gear Ratios (overall) 6th:

  4.436
Chassis

add remove
- Front fork:

  47mm inverted fork with electronically adjustable preload and manually adjustable compression and rebound. Aluminum fork triple clamps
- Rear shocks:

  Linkage-mounted monoshock with automatic electronic preload control and manually adjustable compression & rebound damping
- Wheels, front type:

  Aluminum cast, satin black
- Wheels, rear type:

  Aluminum cast, satin black
- Brakes, type:

  Front: dual rotor, floating, hub mounted; Rear: solid uniform expansion rotor
- Brakes, caliper type:

  Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
- ABS:

  Standard
Infotainment

add remove
- Type:

  Color TFT w/ Touch
- Headset specifications (if equipped):

  Bluetooth
- Voice Recognition Languages: Phone functions only:

  Phone dependent
- Voice Recognition Languages: Tuner / Media / Navigation:

  Phone dependent
- Text-to-Speech (TTS) languages:

  Phone dependent
- Rider / passenger intercom:

  Headset function only
- Vehicle information screen:

  TPMS, Engine temp, Battery Voltage, Ambient Air Temp
- USB:

  Charging and Instrument update, USB-C, 5V, 3A
- Bluetooth:

  Phone/Media Supported
